PZEM-004T-100A 3.0 Version AC Single Phase Multifunction Ampere Meter Watt Power Volt Amp Kwh TTL Modbus With Split CT With Case

Description

PZEM-004T-100A 3.0 Version AC Single Phase Multifunction Ampere Meter Watt Power Volt Amp Kwh TTL Modbus With Split CT With Case



• Watt Dielectric Union Modbus Vs Ethernet High Precision Measurement: Accuracy Class 1.0 ensures precise readings for voltage, current, power, and energy.
• Multi-Functional Design: Measures 6 parameters including voltage, current, power, power factor, frequency, and energy.
• Wide Voltage Range: Operates efficiently between 80-260V, suitable for various electrical systems.
• Modbus-RTU Communication: Communicates via Modbus-RTU, enabling seamless integration with diverse devices
• Easy DIY Setup: Comes with a split CT and software, making it a DIY-friendly project for Arduino enthusiasts.

We provide the software to connect it with the PC. If you want to connect it with other terminal device such as PLC, SCM and so on, please prepare the fit able cable and write the program by yourself.

This document describes the specification of the PZEM-004T AC communication module, the module is mainly used for measuring AC voltage, current, active power, frequency, power factor and active energy, the module is without display function, the data is read through the TTL interface.

PZEM-004T-10A: Measuring Range 10A (Built-in Shunt)

PZEM-004T-100A: Measuring Range 100A (external transformer)

If you need the software, please download it via this link:
http://www.mediafire.com/file/lk5wukg2v5n5iry/004T_software%252Bdriver%252Buser_manual.zip/file



1. Working voltage: 80 ~ 260VAC

2. Test voltage: 80 ~ 260VAC

3. Rated power: 100A/22000W

4. Operating frequency: 45-65Hz

5. Measurement accuracy: 1.0 grade
